Dell N3048 Managed L3 Switch 48X10Gigabit SFP+ Ports
Part Number:
N3048
Need a bulk deal or have questions?
Our enterprise specialists reply within the hour.
Product Overview
Key Features :
Device Type : Switch 48 Ports L3 Managed Stackable
Enclosure Type : Rack-mountable 1u
Subtype : Gigabit Ethernet
Ports : 48 X 10/100/1000 + 2 X 10 Gigabit Sfp+ + 2 X Combo 1000base-t
Performance : Switching Fabric Bandwidth: 260 Gbps Forwarding Performance: 193 Mbps Stacking Bandwidth: 84 Gbps
Capacity : Mac Addresses: 32000 Ipv4 Routes (static): 1024 Ipv6 Routes (static): 1024 Ipv4 Routes (dynamic): 8160 Ipv6 Routes (dynamic): 4096 Maximum Member Ports Per Lag: 8 Maximum Dynamic Ports Per Switch Stack: 144 Lag Groups: 128 Ospf Routes: 8160 Rip Routes: 512 Ecmp Next Hops Per Route: 4 Ecmp Groups: 64 Vlan Routing Interfaces: 128 Vlans Supported: 4094 Multicast Entries (ipv4): 1536 Multicast Entries (ipv6): 512 Arp Entries: 6144 Ndp Entries: 400 Acl: 100 Maximum Rules Per Acl: 1023 Max Acl Rules System-wide: 4096 Maximum Acl Rules Per Interface (ipv4) Egress Rules: 1024 Maximum Acl Rules Per Interface (ipv4) Ingress Rules: 3072 Maximum Acl Rules Per Interface (ipv6) Egress Rules: 512 Maximum Acl Rules Per Interface (ipv6) Ingress Rules: 1021 Maximum Vlan Interfaces With Acls Applied: 24
Mac Address Table Size : 32k Entries
Routing Protocol : Ospf, Rip-1, Rip-2, Igmpv2, Igmp, Vrrp, Ospfv2, Pim-sm, Pim-dm, Igmpv3, Ospfv3, Mldv2, Mld
Remote Management Protocol : Snmp 1, Snmp 2, Rmon 1, Rmon 2, Rmon 3, Rmon 9, Snmp 3, Http, Ssh-2
Encryption Algorithm : Md5, Aes, Ssl, Tls
Authentication Method : Radius, Tacacs+, Secure Shell V.2 (ssh2)
Features : Flow Control, Layer 3 Switching, Layer 2 Switching, Mdi/mdi-x Switch, Auto-negotiation, Load Balancing, Port Mirroring, Stackable, Weighted Round Robin (wrr) Queuing, Broadcast Storm Control, Rapid Spanning Tree Protocol (rstp) Support, Multiple Spanning Tree Protocol (mstp) Support, Access Control List (acl) Support, Quality Of Service (qos), Port Forwarding, Stp Root Guard, Lldp Support, Link Aggregation Control Protocol (lacp), Per-vlan Rapid Spanning Tree (pvrst), Energy Efficient Ethernet, Dynamic Vlan Support (gvrp), Dual Firmware Images, Network Access Control (nac), Tagged Vlan, Generic Vlan Registration Protocol (gvrp), Redundant Fans, Protocol-based Vlans Support
Compliant Standards : Ieee 802.2, Ieee 802.3, Ieee 802.3u, Ieee 802.3z, Ieee 802.1d, Ieee 802.1q, Ieee 802.3ab, Ieee 802.1p, Ieee 802.3x, Ieee 802.3ad (lacp), Ieee 802.1w, Ieee 802.1x, Ieee 802.3ae, Ieee 802.3ac, Ieee 802.1s, Ieee 802.1v, Ieee 802.1ag, Ieee 802.1ab (lldp), Ieee 802.3az
Ram : 1 Gb
Flash Memory : 256 Mb
Expansion / Connectivity :
Interfaces :
48 X Gigabit Lan - Rj-45
2 X 10gbit Lan - Sfp+
2 X Gigabit Lan - Rj-45
1 X Serial (rs-232) - Rj-45 - Management
1 X Usb - Type A
2 X Network Stack Device
Power :
Power Device : Internal Power Supply - Hot-plug
Installed Qty : 1 (installed) / 2 (max)
Power Redundancy : Optional
Power Redundancy Scheme : 1+1 (with Optional Power Supply)
Power Provided : 200 Watt
Power Consumption Operational : 74.8 Watt
Condition : Refurbished.
Availability : In Stock.
Our Warranty : 90 Days.
DELL N3048 Networking N3048 Switch 48 Ports Managed Rack-mountable
Key Features :
Expansion / Connectivity :
Interfaces :
Power :
Condition : Refurbished.
Availability : In Stock.
Our Warranty : 90 Days.
| Part Number: | N3048 |
|---|---|
| Capacity | 48 PORT |
| Condition | Refurbished |
| Manufacturer | DELL |
